Metz, Current Converter TAmini 505 A
| Kód: | 1101810507 |
- The current converter TAmini is used for measuring currents that are beyond the measuring range of the directly connected measuring instrument
| Cena: | dostupná po přihlášení | ||
| Dostupnost: | Brno |
Praha |
na vyžádání |
| Množství: | ks |
|
|
The current converter TAmini is used for measuring currents that are beyond the measuring range of the directly connected measuring instrument.
- Small current converter for mounting on 35 mm DIN rail
- Hole diameter: 21 mm; suitable for cables and rail 20 x 5 mm
Technická specifikace
| Transformer ratio | 50 A / 5 A |
| Nominal frequency | 50 Hz |
| Operating frequency | 47 to 63 Hz |
| Secondary nominal current | 5 A |
| Max. switch-on current | 60 x nominal current smaller than 1 s |
| Max. internal consumption | less than 3 VA |
| Classification | UL-94 V0 |
| Dimensions (W x H x D) | 30 x 44 x 65 mm |
| Operating temperature range | -25 °C to +50 °C |
| Storage temperature range | -40 °C to +85 °C |
Originální text
The current converter TAmini is used for measuring currents that are beyond the measuring range of the directly connected measuring instrument.
- Small current converter for mounting on 35 mm DIN rail
- Hole diameter: 21 mm; suitable for cables and rail 20 x 5 mm
