Kód: | 1108311319 |
Cena: | dostupná po přihlášení | ||
Dostupnost: | Brno |
Praha |
na vyžádání |
Množství: | ks |
|
Protocol | Modbus RTU |
Address range | 00 to 99 |
Bus interface | RS485 (two-wire bus) |
Transmission rate | 1200 to 115200 bit/s |
Operating voltage | 24 V AC/DC ± 10% (SELV) |
Current consumption | 85 mA (AC) / 75 mA (DC) |
Relative duty cycle | 100 % |
Inputs | 10 x digital |
Input / voltage | 30 V DC |
Input / high signal | more than 17 V AC/DC |
Display | Green, red and yellow LED |
Dimensions (W x H x D) | 35 x 69.3 x 60 mm |
Weight | 83 g |
Operating temperature range | -5 °C to +55 °C |
Storage temperature range | -20 °C to +70 °C |
Ingress protection for housing / terminal blocks | IP40 / IP20 |
