Kód: | 11088913 |
Cena: | dostupná po přihlášení | ||
Dostupnost: | Brno |
Praha |
na vyžádání |
Množství: | ks |
|
Protocol | BACnet MS/TP |
Addressing range | 00 to F9 |
Bus interface | RS485 (two-wire bus) |
Transmission rate | 9600 to 115200 baud |
Operating voltage | 24 V AC/DC ± 10% (SELV) |
Current consumption | 100 mA (AC) / 40 mA (DC) |
Relative duty cycle | 100 % |
Inputs | 6 x digital contacts |
Input / switching threshold | 4.5 V DC |
Outputs (relay) | 2 x two-level |
Output / switching voltage | 250 V AC |
Output / current | 6 A / output |
Outputs (digital) | 2 NO (DPST-NO) (photoMOS) |
Output / switching voltage | 40 V AC/DC |
Output / current | 100 mA |
Display | Green, red and yellow LED |
Dimensions (W x H x D) | 50 x 69.3 x 60 mm |
Weight | 126 g |
Operating temperature range | -5 °C to +55 °C |
Storage temperature range | -20 °C to +70 °C |
Ingress protection for housing / terminal blocks | IP40 / IP20 |
