Kód: | 1108511319IP |
Cena: | dostupná po přihlášení | ||
Dostupnost: | Brno |
Praha |
na vyžádání |
Množství: | ks |
|
Protocol | TP/FT-10, free topology |
Neuron | FT5000 |
Transmission rate | 78 KBit/s |
Operating voltage | 24 V AC/DC ± 10% (SELV) |
Current consumption | 63 mA (AC) / 21 mA (DC) |
Relative duty cycle | 100 % |
Recovery time | 550 ms |
Inputs | 10 x contact or voltage |
Input / voltage | 24 V AC/DC |
Input / high signal | more than 8 V AC/DC |
Display | Green and yellow LED |
Dimensions (W x H x D) | 160 x 40.7 x 120 mm |
Weight | 300 g |
Operating temperature range | -5 °C to +55 °C |
Storage temperature range | -20 °C to +70 °C |
Ingress protection for housing / terminal blocks | IP65 / IP20 |
